Motrona Safety Devices
Safety Monitors for Speed, Direction of Rotation, Standstill and Position
The motrona range of SIL3/PLe and SIL2/PLd certified safety devices are intended to detect and monitor machine movements. The purpose is to protect the operator and machine by analyzing speed-, direction-, standstill and position and comparing with pre-selected limits.
For the requirements of increased security criteria according to DIN 61508 or EN ISO 13849 our SIL3/PLe and SIL2/PLd certified DS series offer maximum reliability and safety. With an integrated analog output an additional signal is supplied that can be used as feedback for motion controllers. All these devices and monitors are developed for an easy installation in control cabinets and by the flexible design they are suitable for retrofitting or inclusion in the existing design of an OEM equipment.
SIL3/PLe & SIL2/PLd certified Monitors (Speed, Standstill, Direction of Rotation)
Industrial automation often require the monitoring of speed limit values such as maximum speed, minimum speed, standstill or direction of rotation. Motrona's Safety Monitors are used when increased safety criteria for safety and reliability of a system is required. In particular, if the highest safety standards for man and machine are essential, the safe speed, standstill and direction of rotation monitors of the DS series with the double certificate by DIN 61508 and ISO 13849 offer maximum security.
DS240: Certified Safety Monitors with SinCos Encoder and Signal Splitter
The Safety Motion Monitors for SinCos sensors are suitable for safety-related monitor tasks, e.g. direction of rotation, standstill, overspeed and underspeed.
- Safety functions equivalent to EN 61800-5-2
(SS1, SS2, SOS, SLS, SDl, SSM, SLI, SBC, STO, SMS)
- 1 encoder input with format SIN+, SIN-, COS+, COS- [1 Vss]
- 2 control inputs [HTL / PNP]
- Input frequency up to 500 kHz
- Forced-guided redundant output relay (NO)
- 4 control outputs with push-pull characteristic, short-circuit-proof, [HTL],
each inverse and redundant
- Safety related 14 bit analog output for 4 ... 20 mA (scalable)
DS246: Certified Safety Monitors with SinCos Encoder without Signal Splitter
Performance as DS240, without signal splitter.
DS230: Certified Safety Monitor with Multifunctional Inputs for HTL-, RS422-, SinCos-Sensors and Signal Splitter
Performance as DS240, but different input configuration.
- Safety functions equivalent to EN 61800-5-2
(SS1, SS2, SOS, SLS, SDl, SSM, SLI, SBC, STO, SMS)
- 2 encoder inputs with format SIN+, SIN-, COS+, COS- [1 Vss]
- 2 pulse inputs with format A, /A, B, /B [RS422]
- 2 pulse- or control inputs with format A, B, 90° [HTL / PNP]
(for rotary encoder, proximity switches or commands)
- Input frequency up to 500 kHz
- Forced-guided redundant output relay (NO)
- 4 control outputs with push-pull characteristic, short-circuit-proof,
[HTL], each inverse and redundant
DS236: Certified Safety Monitor with Multifunctional Inputs for HTL-, RS422- and SinCos-Sensors, without Signal Splitter
Performance as DS230, without signal splitter.
BG230: Plug-in Display and Programming Unit
The plug-in display and programming unit BG230 is used for the motrona safety devices of the DS series. This devices contains a huge variety of functions and options of applications. Thanks to its intuitive operation, it is fast, simple and flexible to use. Easy "copy & paste" of system parameters allows the quick transfer to other devices with the same or similar configuration.
The BG230 offers the following features on the safety device:
- Dual channel frequency indicator
- Individual scalable for speed indicator, production rates, etc.
- Editing and saving of the BG230 scaling and safety devices parameters
- Editing and copying of the safety devices parameters
- Visual error messaging
Monitor for Speed, Standstill and Direction of Rotation
These devices are designed as monitoring modules for control cabinet installation. They are used to the monitoring of machine overspeed, underspeed, direction of rotation or standstill. Versions with analog output additionally can be used for control and regulation purposes.
Special features of these devices are the very high frequency range, the fast response and the easy configuration of the speed-, direction- and standstill-detection depending of the used signal formats.
DZ210: Direction and Standstill Monitor
Electronic monitor for monitoring left / right rotation and standstill. With universal pulse inputs for all common incremental encoders and sensors.
- Pulse input with format A, B, 90° [HTL] or A, /A, B, /B [RS422],
also possible for single channel
- Input frequency up to 500 kHz
- 2 output relays with potential-free change-over contact and
2 transistor outputs with High-Side-Driver, short-circuit-proof, [7 ... 30 VDC]
DZ260: Speed Monitor with 3 Output Relays and Analog Output
Compact device for monitoring overspeed, underspeed, standstill and direction of rotation with universal inputs for incremental encoders, proximity switches, light barriers or sensors.
- Pulse input with format A, B, 90° [HTL] or A, /A, B, /B [RS422],
also possible for single channel
- Input frequency up to 1 MHz
- 3 output relays
- 14 Bit analog output for ±10 V or 0/4 ... 20 mA
DZ261: Speed Monitor with 3 Transistor Outputs and Analog Output
Performance as DZ260, but with 3 fast transistor switching outputs instead of relays.
DZ266: Speed Monitor with Analog Output
Performance as DZ260, without relay.
DZ267: Speed Monitor with 3 Output Relays
Performance as DZ260, without analog output.
DZ269: Speed Monitor with 3 Transistor Outputs
Perfomances as DZ260, without analog output.
ZD640: Motion Monitor with 4 Thumbwheel Switches and Output Relays
Motion monitor with position display. Suitable for monitoring for drift, shaft fracture, torsion and slip.
- 2 scalable inputs with format A, /A, B, /B [HTL / TTL / RS422,
single channel, dual channel, symmetric or asymmetric]
- 4 control inputs for PNP / NPN / Namur signals [10 ... 30 VDC]
- Input frequency up to 1 MHz
- 4 fast transistor outputs with push-pull characteristic,
short-circuit-proof [5 ... 30 VDC]
- 4 potential-free output relays
MS640: Motion Monitor for Secure and Redundant Control of 2 Drive Systems
Motion monitor for control and monitoring of admissible and impermissble operating conditions on machinery systems, e. g. speed, standstill, direction of rotation, position, drift, torsion, shaft fracture, slip, illegitimate motion sequences, etc.
- 2 Pulse input with format A, B, 90° [HTL] or A, /A, B, /B [RS422]
- 4 control inputs for PNP / NPN / Namur signals [10 ... 30 VDC]
- 6 logical inputs for PNP signals [10 ... 30 VDC]
- Input frequency up to 500 kHz
- 4 fast transistor outputs with push-pull characteristic,
short-circuit-proof [5 ... 30 VDC]
- 4 forced-guided redundant output relays with potential free change-over contact
Motrona Digital Indicators
Precise monitoring for almost all applications
Our display and evaluation systems ensure a precise monitoring of analog, pulse and absolute value information. The significant parameters for rotating and linear processes are precisely monitored, evaluated and displayed.
The electronic and pulse counters, process and position indicators distinguish themselves by offering a high dynamic range, short response times and an input frequency up to 1 MHz. Our display devices are able to perform complex data manipulation such as summing, difference, filtering, linearization and totalization and comparison between input variables. Additionally, the digital displays provide up to four preset values for relay and transistor outputs. The set-up procedures are straightforward, using an intuitive menu system for entry and adjustment of parameters. Display devices equipped with a serial interface also allow operation and configuration using our OS user software.
Process Indicators for Analog Norm Signals or DMS Sensors
Short reaction time, precision as well as exceptional technical characteristics, accompanied by the flexible configuration of the operating mode - this is what motrona analog process displays stand for.
Our process displays are mainly used in the fields of automation and instrumentation in order to evaluate and visualize analog standard signals for ±10 V or 0/4 ... 20 mA. Dual-channel versions with two inputs are also available. That allow users to display sums, differences or ratios. Furthermore we offer process displays with which the signals of strain gauges or strain gauge sensors can be processed.
With our variety of process indicators, we provide the tailor-made product solution for almost all requirements - from simple compact process displays to sophisticated multi-function devices with numerous operating modes, preselections and any outputs.
AX350: touchMATRIX Process Indicator with two 16 bit Analog Inputs
Process indicator with resistive touch panel and multi-colour graphic display (red, green, yellow). Visualization of plain text, symbols and units. Arbitrarily combinable, modular configuration with analog output, switching outputs, relay, serial interface (Modbus) and 115 ... 230 VAC.
- 2 universal 16 bit analog inputs for ±10 V or 0/4 … 20 mA
- 3 control inputs for HTL / PNP signals
- High accuracy reference output 10 V for potentiometers > 1 kOhm
» More Information » Request
AX350 Options: for touchMATRIX Process Indicators
Individual configuration of the touchMATRIX process displays are possible with various options. All options can be combined.
- Option AC: Power supply with 115 / 230 VAC
- Option AO: 16 bit analog output, 4 control outputs, RS232 interface
- Option CO: 4 control outputs, RS232 interface
- Option RL: 2 relay outputs
AX020: Process Indicator for Analog Signals
Scalable compact digital display for visualization of analog standard signals.
- Scalable 14 bit analog input for 0 ... 10 V or 0/4 ... 20 mA
- Power supply 24 VDC
AX320: Process Indicator (DC) with Preset-Relays
Comprehensively programmable process display with analog input for standard signals.
- 2 preset-relays
- 2 control inputs
- Power supply 10 ... 30 VDC
AX321: Process Indicator (DC) for DMS / Strain Sensors
Process indication for analog strain gauge signals.
- 2 preset-relays
- 2 control inputs
- Power supply 10 ... 30 VDC
» More Information » Request
AX322: Process Indicator (AC) with Preset-Relays
Performance as AX320 but with AC power supply 90 ... 240 VAC.
» More Information » Request
AX323: Process Indicator (AC) for DMS / Strain Sensors
Performance as AX321 but with AC power supply 90 ... 240 VAC.
AX342: Process Indicator with Relay Outputs and Serial Interface
Universally scalable process indicator with two 14 bit analog inputs and extensive programmable functions such as tara, programmable linearization, etc. Suitable for visualization of measurement values, sums, differences and ratio.
- 2 analog inputs
- 2 limit values / output relays
- Power supply 24 VDC
- Serial RS232 / RS485 interface (switchable)
AX345: Process Indicators with 2 Standard Signal Analog Inputs
Extensive programmable functions, with no outputs.
- 2 separat scalable analog inputs, each 0 ... 10 V or 0/4 ... 20 mA
- Power supply 115 / 230 VAC and 24 VDC
AX346: Dual Process Indicator with Analog Output
Performance as AX345, with scalable analog output.
AX347: Process Indicator with 2 Preset Values and 2 Transistor Outputs
Performance as AX345, with 2 preset values for the control of 2 transistor switching outputs.
AX348: Process Indicator with Serial RS232 / RS485 interface
Performance as AX345, with serial RS232 / RS485 interface.
Digital Directional Meters, Difference Meters and Preselection Counters
Electronic pulse counters from motrona are used in automation and mechanical englineering in order to display, measure, calculate or control variables such as lengths, times or numbers. Our product range offers solutions from the classic pulse counter to multifunctional and extensively programmable direction counters, differential counters and preset counters with switching function as well as various outputs and interfaces.
DX350: touchMATRIX Digital Indicator (HTL)
Pulse counter (HTL) with resistive touchscreen and multi-color graphic display (red, green, yellow). Digital display for incremental encoders or sensor signals.
- Pulse input with format A, B, 90° [HTL], single channel as an option
- HTL inputs for encoder and sensors with NPN / PNP or NAMUR switching characteristics
- Input frequency up to 250 kHz
- 3 control inputs for HTL / PNP signals
» More Information » Request
DX350 Options: for touchMATRIX Digital Indicators
Individual configuration of the touchMATRIX process displays are possible with various options. All options can be combined.
- Option AC: Power supply with 115 / 230 VAC
- Option AO: 16 bit analog output, 4 control outputs, RS232 interface
- Option CO: 4 control outputs, RS232 interface
- Option RL: 2 relay outputs
DX355: touchMATRIX Digital Indicator (HTL / RS422)
"High-End" device with 2 incremental HTL / RS422 control inputs. Input frequency up to 1 MHz and a switchable encoder supply of 5 / 24 VDC. All other functions equal to DX350.
DX355 Options: for touchMATRIX Digital Indicators
Individual configuration of the touchMATRIX process displays are possible with various options. All options can be combined.
- Option AC: Power supply with 115 / 230 VAC
- Option AO: 16 bit analog output, 4 control outputs, RS232 interface
- Option CO: 4 control outputs, RS232 interface
- Option RL: 2 relay outputs
ZX020: Small-sized Position- and Event Counter
Universally programmable incremental display counter in miniature housing.
- Pulse input with format A, B, 90° [HTL]
- Static input for Set / Reset [HTL]
- Input frequency up to 20 kHz
DX342: Counter with 2 Relay Outputs and Serial Interface
Up / Down pulse counter with 2 relays and serial RS232 / RS485 interface.
- Pulse input with format A, B, 90° [HTL], [TTL] as an option
- Static input for Set / Reset [HTL]
- 2 relay outputs
- Input frequency up to 100 kHz
- Power supply 24 VDC
- Serial RS232 / RS485 interface (switchable)
DX345: Counter for Incremental Encoders (without Output)
Precise up / down counter with extensive programmable operating modes and static input. Basic version without outputs.
- Pulse input with format A, B, 90° [HTL], [TTL] as an option
- Static input for Set / Reset [HTL]
- Input frequency up to 100 kHz
- Power supply 115 / 230 VAC and 24 VDC
DX346: Counter with Analog Output
Performance as DX345, but with a scalable 14 bit analog output ±10 V or
0/4 ... 20 mA.
DX347: Counter with 2 Transistor Outputs
Performance as DX345, but with 2 preset values and 2 transistor outputs.
DX348: Counter with Serial Interface
Performance as DX345, but with RS232- / RS485 interface.
ZA330: Dual-/Differential-Counter 8 digit with Analog Output
Fast universal counter up to 1 MHz with analog output and 8 digit display.
- 2 scalable inputs with format A, /A, B, /B
[HTL / TTL / RS422, single channel, dual channel, symmetric or asymmetric]
- 4 control inputs for PNP / NPN / Namur signals [10 ... 30 VDC]
- Input frequency up to 1 MHz
- Scalable 14 bit analog output ±10 V or 0/4 … 20 mA
- 4 fast transistor outputs with push-pull characteristic, short-circuit-proof
[5 ... 30 VDC]
ZD330: Dual-/Differential-Counter 8 digit
Performance as ZA330, but without analog output.
ZA340: Dual-/Differential-Counter 6 digit with Analog Output
Performance as ZA330, but with 6 digit display.
ZD340: Dual-/Differential-Counter 6 digit
Performance as ZD330, but with 6 digit display.
ZD630: Preselect Counter 8 digits (3.78 x 3.78 ")
The universal counters of the ZD / ZA / ZR 630-640 series are equipped as standard with output relay, dimensions 96 x 96 x 140 mm (3.78 x 3.78 x 5.51 ").
The range of functions corresponds otherwise to that of the ZD / ZA / ZR 330-340 series.
- 2 scalable inputs with format A, /A, B, /B
[HTL / TTL / RS422, single channel, dual channel, symmetric or asymmetric]
- 4 control inputs for PNP / NPN / Namur signals [10 ... 30 VDC]
- Input frequency up to 1 MHz
- 4 fast transistor outputs with push-pull characteristic,
short-circuit-proof [5 ... 30 VDC]
- 4 outputs relays
ZD632: Preselect Counter 8 digits with 2 front-mounted Thumbwheel Switches
Performance as ZD630, with 2 front-panel preselections for the switching function.
ZD634: Preselect Counter 8 digits with 4 front-mounted Thumbwheel Switches
Performance as ZD630, but with 4 front-panel preselections for the switching function.
ZD640: Preselect Counter 6 digits
Performance as ZD630, but with 6 digit display.
ZD642: Preselect Counter 6 digits with 2 front-mounted Thumbwheel Switches
Performance as ZD640, with 2 front-mounted thumbwheel switches.
ZD644: Preselect Counter 6 digits with 4 front-mounted Thumbwheel Switches
Performance as ZD640, with 4 front-mounted thumbwheel switches.
ZA630: Preselect Counter 8 digits with Analog Output
Performance as ZD630 with scalable analog output.
ZA632: Preselect Counter 8 digits with Analog Output and 2 front-mounted Thumbwheel Switches
Performance as ZD632, with analog output.
ZA634: Preselect Counter 8 digits with Analog Output and 4 front-mounted Thumbwheel Switches
Performance as ZD634 with scalable analog output.
ZA640: Preselect Counter 6 digits with Analog Output
Performance as ZA630, but with 6 digit display.
ZA642: Preselect Counter 6 digits with Analog Output and 2 front-mounted Thumbwheel Switches
Performance as ZA632, but with 6 digit display.
ZA644: Preselect Counter 6 digits with Analog Output and 4 front-mounted Thumbwheel Switches
Performance as ZA634,but with 6 digit display.
Universal Indicators and Timers for Frequencies, Speeds, Times and Machine Strokes
Multifunctional displays from motrona are used in automation and mechanical engineering in order to visualize, record, calculate or control frequencies, times and (in the case of dual-channel devices) sums, differences or ratios. This results in applications such as tachometer, speed meter, sum-, difference- or ratio-display, baking time display, industrial stopwatch or counter. With our digital frequency meters, we offer the right device for almost every industrial machine requirement. The devices process the signals of conventional incremental rotary encoders, sensors, light barriers, proximity switches or length measuring systems.
DX350: touchMATRIX Digital Indicator (HTL)
HTL frequency counter, tachometer, speed counter with resistive touchscreen and multi-color graphic display (red, green, yellow). Digital indicator for incremental encoders or sensor signals.
- Pulse input with format A, B, 90° [HTL], single channel as an option
- HTL inputs for encoder and sensors with NPN / PNP or NAMUR switching characteristics
- Input frequency up to 250 kHz
- 3 control inputs for HTL / PNP signals
DX350 Options: for touchMATRIX Digital Indicators
Individual configuration of the touchMATRIX process displays are possible with various options. All options can be combined.
- Option AC: Power supply with 115 / 230 VAC
- Option AO: 16 bit analog output, 4 control outputs, RS232 interface
- Option CO: 4 control outputs, RS232 interface
- Option RL: 2 relay outputs
DX355: touchMATRIX Graphic Display (HTL / RS422)
"High-End" device with 2 incremental HTL / RS422 control inputs. Input frequency up to 1 MHz and a switchable encoder supply of 5 / 24 VDC. All other functions equal to DX350.
DX355 Options: for touchMATRIX Digital Indicators
Individual configuration of the touchMATRIX process displays are possible with various options. All options can be combined.
- Option AC: Power supply with 115 / 230 VAC
- Option AO: 16 bit analog output, 4 control outputs, RS232 interface
- Option CO: 4 control outputs, RS232 interface
- Option RL: 2 relay outputs
DX020: Small-sized Tachometer and Frequency Counter
Programmable indicator for reliable measurement of RPM, speed and frequency.
- Single channel pulse input [HTL]
- Input frequency up to 20 kHz
- Power supply 24 VDC
DX342: Frequency Meter with 2 Relay Outputs and Interface
Multi-function indicator with many operating modes, eg as a speed measuring device, tachometer, timer or counter. Equipped with 2 limit values, 2 output relays and RS232 / RS485 interface.
- Pulse input with format A, B, 90° [HTL], [TTL] as an option
- Static input for Set / Reset [HTL]
- 2 relay outputs
- Input frequency up to 100 kHz
- Power supply 24 VDC
- Serial RS232 / RS485 interface (switchable)
DX345: Universal Frequency Meter / Tachometer / Timer
Multifunctional display with numerous operating modes (e.g. frequency, speed, pulses, times and reciprocal speeds). Basic version without outputs.
- Pulse input with format A, B, 90° [HTL], [TTL] as an option
- Static input for Set / Reset [HTL]
- Input frequency up to 100 kHz
- Power supply 115 / 230 VAC and 24 VDC
DX346: Frequency Meter with Analog Output
Performance as DX345, with scalable 14 bit analog output ±10 V or 0/4 ... 20 m.
DX347: Frequency Meter with 2 Transistor Outputs
Performance as DX345, but with 2 Transistor Outputs.
DX348: Frequency Meter with RS232 / RS485 Interface
Performance as DX345, but with serial RS232 / RS485 interface (switchable).
SA340: Dual Frequency Meter 6 digit with Analog Output
Tachometer / frequency meters with 6 digit LED display, two independent pulse inputs and analog output.
- 2 scalable inputs with format A, /A, B, /B
[HTL / TTL / RS422, single channel, dual channel, symmetric or asymmetric]
- 4 control inputs for PNP / NPN / Namur signals [10 ... 30 VDC]
- Input frequency up to 1 MHz
- Scalable 14 bit analog output ±10 V or 0/4 ... 20 mA
- 4 fast transistor outputs with push-pull characteristic, short-circuit-proof
[5 ... 30 VDC]
SD340: Dual Frequency Meter 6 digit
Performance as SA340, but without analog output.
SA640: Dual Frequency Meter 6 digit with 4 Relays and Analog Output
Performance as SA340, but with 4 relays and dimension of 96 x 96 x 140 mm (3.78 x 3.78 x 5.51 ").
SA642: Dual Frequency Meter 6 digit with 4 Relays, Analog Output and with 2 front-mounted Thumbwheel Switches
Performance as SA640, but additionally with 2 front-panel preselections for the switching function.
SA644: Dual Frequency Meter 6 digit with 4 Relays, Analog Output and with 4 front-mounted Thumbwheel Switches
Performance as SA640, but additionally with 4 front-panel preselections for the switching function.
SD640: Dual Frequency Meter 6 digit with 4 Relays
Performance as SD340, but with 4 relays and dimension of 96 x 96 x 140 mm (3.78 x 3.78 x 5.51 ").
SD642: Dual Frequency Meter 6 digit with 4 Relays and 2 front-mounted Thumbwheel Switches
Performance as SD640,but additionally with 2 front-panel preselections for the switching function.
SD644: Dual Frequency Meter 6 digit with 4 Relays and 4 front-mounted Thumbwheel Switches
Performance as SD640, but additionally with 4 front-panel preselections for the
SSI Indicators for SSI Absolute Encoders and Absolute Measuring Systems
With the SSI Indicators, motrona offers a further variant of its display devices. In conjunction with absolute encoders, absolute measuring systems or magnet sensors, the motrona SSI displays offer a cost-effective solution for displaying, recording, calculating or controlling variables such as lengths, times or numbers of units in automation and instrumentation - with all the advantages of motrona quality.
IX350: touchMATRIX SSI Indicator for Absolute Encoders
SSI indicator for absolute encoders with resistive touchscreen and multi-color graphic display (red, green, yellow). Digital indicator for incremental encoders or sensor signals.
- SSI input with format DATA+, DATA-, CLOCK+, CLOCK-
- SSI clock frequencies up to 1 MHz
- Master or Slave operation
- For single turn and multi turn encoders with 10 … 32 Bit
IX350 Options: for touchMATRIX SSI Indicators
Individual configuration of the touchMATRIX SSI displays are possible with various options. All options can be combined.
- Option AC: Power supply with 115 / 230 VAC
- Option AO: 16 bit analog output, 4 control outputs, RS232 interface
- Option CO: 4 control outputs, RS232 interface
- Option RL: 2 relay outputs
IX355: touchMATRIX SSI Indicator for Absolute Encoders
"High-End" version with wire break monitoring and switchable encoder supply of 5 / 24 VDC. All other functions equal to IX350.
IX355 Options: for touchMATRIX SSI Indicators
Individual configuration of the touchMATRIX SSI displays are possible with various options. All options can be combined.
- Option AC: Power supply with 115 / 230 VAC
- Option AO: 16 bit analog output, 4 control outputs, RS232 interface
- Option CO: 4 control outputs, RS232 interface
- Option RL: 2 relay outputs
IX342: SSI Indicator with 2 Relays and RS232 / RS485 Interface
Versatile indicator unit for SSI encoder, with 2 relay outputs and serial interface.
- SSI input with format DATA+, DATA-, CLOCK+, CLOCK-
- 3 control inputs for PNP / NPN / signals [10 ... 30 VDC]
- 2 output relays with potential free change-over contact
- Power supply 24 VDC
- Serial RS232 / RS485 interface Schnittstelle (switchable)
IX345: SSI Indicator
SSI indicator unit for evaluation of single- or multi-turn absolute encoders. Suitable for all SSI formats and codes up to 25 bits. Free scalability and zero definition. Programmable bit blanking, linearization, concentricity function and many other funtions. Operation in master and slave mode.
- SSI input with format DATA+, DATA-, CLOCK+, CLOCK-
- 3 control inputs for PNP / NPN / signals [10 ... 30 VDC]
- SSI frequency range 100 Hz ... 1 MHz
- Power supply 115 / 230 VAC and 24 VDC
IX346: SSI Indicator with Analog Output
Performance as IX345, but additionally with scalable 14 bit analog output.
IX347: SSI Indicator with 2 Preset Values and 2 Transistor Outputs
Performance as IX345, but additionally with two preset values and transistor outputs.
IX348: SSI Indicator with serial RS232 / RS485 Interface
Performance as IX345, but additionally with serial RS232 / RS485 interface (switchable).
ID330: Dual SSI Indicator 8 digits
The position indicators with dual SSI encoder input have been designed to close a gap with multiple indicating and counting applications, which cannot be accomplished by the standard SSI indicators or incremental counters available on the market. Many applications require to evaluate the signals of two SSI measuring systems, and to compare the results with respect to the sum or the difference. In certain applications it is necessary to compare position signals from an SSI encoder with other information coming from an incremental encoder.
- 2 scalable inputs with format DATA+, DATA-, CLOCK+, CLOCK- [SSI, absolute]
or A, /A, B, /B [RS422, incremental]
- 4 control inputs for PNP / NPN / Namur signals [10 ... 30 VDC]
- Input frequency up to 1 MHz
- 4 fast transistor outputs with push-pull characteristic,
short-circuit-proof [5 ... 30 VDC]
- Power supply 24 VAC and 17 ... 40 VDC
ID340: Dual SSI Indicator 6 digits
Performance as ID330, but with 6 digit display.
IA330: Dual SSI Indicator 8 digits with Analog Output
Performance as ID330, but with scalable 14 bit analog output.
IA340: Dual SSI Indicator 6 digits with Analog Output
Performance as IA330, but with 6 digit display.
ID630: Dual SSI Indicator 8 digits with 4 Relays (96 x 96 mm)
Performance as ID330, but with 4 output relays and dimension 96 x 96 x 140 mm (3.78 x 3.78 x 5.51 ").
ID632: Dual SSI Indicator 8 digits with 4 Relays and 2 front-mounted Thumbwheel Switches
Performance as ID630, but additionally with 2 front-panel preselections for the switching function.
ID634: Dual SSI Indicator 8 digits with 4 Relays and 2 front-mounted Thumbwheel Switches
Performance as ID630, but additionally with 4 front-panel preselections for the switching function.
ID640: Dual SSI Indicator 6 digits with 4 Relays (96 x 96 mm)
Performance as ID630, but with 6 digit display.
ID642: Dual SSI Indicator 6 digits with 4 Relays and 2 front-mounted Thumbwheel Switches
Performance as ID640, but additionally with 2 front-panel preselections for the switching function.
ID644: Dual SSI Indicator 6 digits with 4 Relays and 4 front-mounted Thumbwheel Switches
Performance as ID640, but additionally with 4 front-panel preselections for the switching function.
IA630: Dual SSI Indicator 8 digit with 4 Relays and Analog Output
Performance as ID630, but additionally with scalable 14 bit analog output.
IA632: Dual SSI Indicator 8 digits with 4 Relays, Analog Output and 2 front-mounted Thumbwheel Switches
Performance as IA630, but additionally with 2 front-panel preselections for the switching function.
IA634: Dual SSI Indicator 8 digits with 4 Relays, Analog Output and 4 front-mounted Thumbwheel Switches
Performance as IA630, but additionally with 4 front-panel preselections for the switching function.
IA640: Dual SSI Indicator 6 digit with 4 Relays and Analog Output (96 x 96 mm)
Performance as IA630, but with 6 digit display.
IA642: Dual SSI Indicator 6 digits with 4 Relays, Analog Output and 2 front-mounted Thumbwheel Switches
Performance as IA640, but additionally with 2 front-panel preselections for the switching function.
IA644: Dual SSI Indicator 6 digits with 4 Relays, Analog Output and 2 front-mounted Thumbwheel Switches
Performance as IA640, but additionally with 4 front-panel preselections for the switching function.
CAN-Bus / PROFIBUS Indicators
The following devices are suitable for the "on-site" display of process values and/or for simple remote setting of individual operating parameters to machines and systems, that networked via fieldbus with CAN-Bus or PROFIBUS communication.
PB340: Fieldbus Indicator for PROFIBUS Process Values
Fieldbus indicator for PROFIBUS process values.
- Power supply 10 ... 30 VDC
- Compact norm panel housing
- 6 digits LED display with 15 mm height
» More Information » Request
CA340: Fieldbus Indicator for CAN-Bus (SDO and PDO)
Fieldbus display for CAN bus actual values and any parameters. Performance as PB340.
PB306: Simple Preset Unit for PROFIBUS
Remote control for PROFIBUS networks for panel mounting.
- Power supply 10 ... 30 VDC
- Compact norm panel housing
- Preset range: 6 digits or 5 digits with sign
CA306: Simple Preset Unit for CAN-Bus
Preset unit for remote adjustment via CANopen interface. Performance as PB306.
PB541: PROFIBUS Indicator & Preset Unit as Combination
Combination of PROFIBUS display and remote control in one housing.
CA541: CAN-Bus Indicator & Preset Unit as Combination
Combination of CAN-Bus display and remote control in one housing.
Motrona Motion Controller
Outstanding dynamic at highest level of accurancy and precision
Our Motion Controllers are implemented in numerous applications in the field of modern drive technology. The firmware library includes optimized routines for applications such as drive synchronization, index or intermitted printing, label-printing, rotary cutters, flying shears and eccentric scissors.
As other motrona products, the set-up procedures are simple and intuitive. The highly integrated Motion Controllers feature by a very high cut-off frequency up to 2 MHz, a very flexible bus architecture as well as a variable input configuration of encoders and sensors.
A unique feature of the MC800 drive controller is the integrated tandem drive controller which enables achieving the acceleration requirement of a slave axis by distributing the power on two independent drives.
Synchronous Controllers (Electronic Shaft or Gearbox) for Synchronization of Speed, Events, Positions, Print Marks Regler
All synchronization controllers shown on this site operate according to the Master- Slave principle. Where the Master can freely move with any motion profile under control of any remote speed reference, the synchronizer will control one or several Slaves to exactly follow the Master motion in terms of position and speed.
The control is based on incremental position feedback by means of encoders on both sides. Many applications just use a measuring wheel with encoder instead of a Master drive. It is possible to preset every speed or gear ratio by means of adjustable impulse scaling factors.
All units can accept marker pulses from the encoders and from remote proximity switches or photocells, to automatically produce the correct position with pitch or cycle related applications. motrona synchronous controllers can operate with any kind of speed variable drives (AC inverter, DC, Servo or hydraulic type) that follow to a ±10 V speed reference signal. The extremely fast position control loop provides excellent performance even with highly dynamic applications.
Application examples / movies:
Animation: Synchronization of Drives MC800
Film 01: Synchronization of product position with machine cycle
Film 02: Synchronization of punch roll with pre-printed cardboard
Film 03: Synchronization of individually driven printing screens with a textile printing machine
BY340: Synchronous Controller for 1 Follower Axis
Low-cost Controllers for Synchronizaiton. Speed ratio adjustable by keypad.
- 2 pulse inputs with format A, B, 90° [HTL] or A, /A, B, /B [RS422]
- 4 control inputs for HTL / PNP / NPN / Namur signals [10 ... 30 VDC]
- Input frequency up to 300 kHz
- 4 fast transistor outputs, with push-pull charackteristics, short-circuit-proof
[5 … 30 VDC]
- Scalable 14 bit analog output (±10 V or 0/4 … 20 mA)
BY641: Master / Slave Synchronizers with 4 Relays
Performance as BY340, but with 4 relays and front-side thumbwheel switches for speed ratio adjustment.
BY701-Firmware: Synchronization of Drives
With the use of BY701 firmware, the MC700 controller provides excellent solutions with all kind of multi-axes synchronizing applications. Numerous possibilities for control of relative phase, position, index and print mark evaluation are available.
Controller for Flying Operation (Flying Saws, Shears, Punchers etc.)
Application examples / movies:
Animation: Flying Saw MC800
Film 04: Steel profile plant, cut-to-length steel tubes
Film 05: Cut-to-length of aluminium plates
Film 06: Cut-to-length of steel profile
FS701-Firmware: Flying Material Processing
In combination with the application firmware FS701, the universal MC700 hardware allows high-precision processing in machine applications such as "flying saws", "flying shears" and similar applications.
FS801-Firmware: Flying Material Processing
By using this application firmware, the MC800 controller is equipped for motion control tasks with typical “on-the-fly-processing” machines (e. g. sawing, cutting, punching, drilling, etc.).
Compared to the FS701 firmware, a significantly higher dynamic is achieved by using the combination FS801 firmware with MC800. In addition, processing to various sensor systems and fieldbus architectures is possible.
FS340: Controller for Flying Saws and Shears
Compact and low priced Controller for machining "on the fly".
- 2 pulse inputs with format A, B, 90° [HTL] or A, /A, B, /B [RS422]
- 4 control inputs for HTL / PNP / NPN / Namur signals [10 ... 30 VDC]
- Input frequency up to 300 kHz
- 4 fast transistor outputs, push-pull, short-circuit-proof [5 … 30 VDC]
- 1 scalable 14 bit analog output (±10 V or 0/4 … 20 mA)
FS641: Controller for Machining "On the Fly"
Performance as FS340, but with front-end cutting length specification and 4 output relays.
Controller for Rotating Cross Cutters (Paper, Corrugated Board etc.), for Rotating Punchers and other Rotary Operations
Application examples / movies:
Animation: Rotating cross cutters MC800
Film 07: Cut-to-length of corrugated cardboard
CT803-Firmware: Rotating Cross Cutters
With firmware CT803, the new universal Motion-Controller MC800 with an integrated tandem drive-controller, flexible input configuration for sensors and adaptive interface structure is suitable for rotating processes.
CT703-Firmware: Rotating Cross Cutters
Rotary cutters and other rotary applications require high dynamics, precise cuts and short position control cycles. These requirements will be complied by using the CT703 firmware and the MC700 motion controller.
Typical applications are intermittent or rotary operations like cutting, perforating,
printing, sealing, adhesion, applying, labeling and many more.
CT340: Controller for Rotary Cutters
Easy control for rotating pressure, punching and sealing rollers. Short position control and precise cuts, even during speed changes.
- 2 pulse inputs with format A, B, 90° [HTL] or A, /A, B, /B [RS422]
- 4 control inputs for HTL / PNP / NPN / Namur signals [10 ... 30 VDC]
- Input frequency up to 300 kHz
- 4 fast transistor outputs, push-pull, short-circuit-proof [5 … 30 VDC]
- 1 scalable 14 bit analog output (±10 V or 0/4 … 20 mA)
CT641: Controller with 4 Relays and front-mounted Thumbwheel Switches
Performance as CT340, but additionally with 4 relays outputs and cutting length adjustable by thumbwheel switch on front.
Controller for Rotary Shears and Eccentric Shears for use with Cut-to-Length Lines in Coil Steel Industry
Application examples / movies:
Animation: Eccentric Shears MC700
Animation: Rotary Drilling Application
Film 08: Rotary Shear and Cut-to-Length Line
CT701-Firmware: Eccentric Material Processing
The firmware CT701, in combination with the controller MC700 offers a maximum processing performance with guillotine or eccentric shears in cut-to-length-lines.
Controller for Tubular Bag Packing Machines (Pillow Type Packing)
Application examples / movies:
Animation: Tubular Bag Packing Machine
Film 09: Packing and sealing of choco bars
TB701-Firmware: Tubular Bag Packing Machine
Due to highly dynamic motion profiles, the combination of firmware TB701 and MC700 controller works very precisely and is optimized for tubular bag packing machines (e.g.“pillow packaging”).
1-4 axes Controller for Winding, Wire Traverse and Tension Control
(Winding Calculator, Tension Controller)
Application examples / movies:
Animation: Controller for Rewinder application MC700
Animation: Cable Winder and Traverse MC700
WR701-Firmware: Winding and Tension Applications
In combination with the motrona controller MC700, the firmware WR701 is suitable to implement all combinations of drives with rewinder, uncoiler, line drive, web tension control and transverse routing.
Motion Controller for Intermittent Printing, Label Printing, Rotary Punching etc.
Application examples / movies:
Animation: Intermittent Label Printing MC700
Animation: Intermittent Printing MC700
Film 10: Intermittent Printing of Bottle Labels
MC700: Intermittent Printing, Label Printing, Rotary Punching
For numerous applications in the fields of printing, punching and labeling, motrona has developed corresponding firmware, which can be used in combination with the MC700 hardware. Thus, we are able to offer ready and tested solutions for a variety of machine applications.
Please do not hesitate to contact us - our engineers will be pleased to advise you.
Flexible Single-Axis Positioning Controls for various Positioning Applications
Application examples / movies:
Animation: Positioning Control
PS340: Single Axis Position Controller
1 axis positioning controller with extremely short control loop, analog output and 4 transistor outputs. Very suitable for smaller machines.
- 2 pulse inputs with format A, B, 90° [HTL] or A, /A, B, /B [RS422]
- 4 control inputs for HTL / PNP / NPN / Namur signals [10 ... 30 VDC]
- Input frequency up to 300 kHz
- 4 fast transistor outputs, push-pull, short-circuit-proof [5 … 30 VDC]
- 1 scalable 14 bit analog output (±10 V or 0/4 … 20 mA)
PS641: Single Axis Position Controller with 4 Relay Outputs
Performance as PS340, but additionally with 4 relay outputs and front-side thumbwheel switches for incremental positioning. Dimension 96 x 96 x 140 mm (3.78 x 3.78 x 5.51").
Signal Converters
Maximum flexibility with extremly short conversion time and high frequency limit
Our signal converters are characterized by a fast conversion time, a wide bandwidth and maximum flexibility classed among the World’s Best in industrial automation.
For requirements demanding safe processing and reliable transmission of encoder and sensor signals our frequency dividers, frequency multipliers, pulse dividers and level converters have no peers.
Converters from motrona convince by easy handling and simple set-up of parameters whereby scaling is performed by DIL switches or TEACH buttons. Programmable linearization, digital filters or window functions are further features of our complex modules.
Accessories
As your competent partner for complex applications in industrial automation and drive technology, we also ensure that the components related to our core assortment perfectly match to our products.
ES001: Incremental Encoder Simulator
This simulator of incremental encoder signals also produces counted pulse sequences of any pulse number.
PB251: PROFIBUS serial Gateway
Cost-effective, powerful gateway for connecting motrona devices to a PROFIBUS (DPV1).
BT348: Mini Operator Terminal
Simple operating unit for entering and readout individual parameters via serial interface. Suitable as a remote display for all motrona devices with serial interface.
NT215: 24 VDC / 15 W Universal Power Pack
Affordable compact power supply unit for all motrona devices with 24 VDC input / 15 W output (Lambda).
RL203: Relay Circuit Board
2 potential-free standard changer relays.
RL204: Relais Circuit Board (Safety)
2 potential-free safety changer relays with forced guided contacts.
SM300: Mounting Clamps and Brackets
suitable for display units with front dimension 96 x 48 mm.
SM600: Mounting Clamps and Brackets
suitable for display units with front dimension 96 x 96 mm.
TG300: Table Housing
suitable for display units with front dimension 96 x 48 mm (fits not to Profibus indicator PB340).
CK232: Connectivity Kit USB / RS232
This set consists of an USB to RS232 converter compatible to all existing Windows versions, including a serial RS232 cable for connection between converter and motrona unit.
One connector Sub-D-9 (male) and one connector Sub-D-9 (female), cable length 3 meters (approx. 10 feet).
USBAA: USB 3.0 cable
for connection between PC and the motrona unit UZ210. Both connectors are type A, cable length 2 m (approx. 6.5 feet).
Assembled Cables
SK232: RS232 cable
1 connector Sub-D-9 (male) and 1 connector Sub-D-9 (female).
FK470: Ribbon cable
Sub-D-9 connectors (male) on both sides.
Sub-D-Connectors (without cable)
DS009: Sub-D-connector 9-position (male)
DB009: Sub-D-connector 9-position (female)
DS025: Sub-D-Connector 25-position (male)
DB025: Sub-D-Connector 25-position (female)
VTxxx: Protective Caps and Plexiglas Bonnets
To increase the protection class with dusty or wet environment, several types of protection caps are available for motrona units.
CI700: CAN-Bus Interface
CAN-Bus interface for motrona Motion Controller MC700 / MC720.
CI800: CANopen Interface Module
Interface for motrona MC800 motion controller.
MB800: Modbus RTU Interface Module
Interface module for motrona MC800 motion controller.
PB800: Profibus DPV1 Interface Module
Interface for motrona Motion Controller MC800.
Motrona Ürünleri ile uygun rekabetçi fiyaları almak için müşteri temsilçimiz ile http://www.imajteknik.com.tr/bize-ulasin veya Fiyat teklifi formunu doldurarak mesaj bırakmanız halinde satış muhendislerimiz en kısa zamanda sizinle irtibat kuracaklardır
